An M12 machine vision lens optimized for measurement, positioning, defect detection and code reading, with five aperture options, 6MP resolution, -1.54% distortion and support for ultra-short working distances.
Source & evidence
Supplier website M12 series lenses are optimized for machine vision applications. Widely used in measurement, positioning, defect detection and code reading. PRODUCT FEATURES ▶ 5 aperture options F4, F5.6,F7,F8,F11 ▶ 6MP high resolution, high uniformity of picture clarity ▶ -1.54% Low distortion, excellent relative illumination ▶ Maintains excellent optical properties at different object distances ▶ Supports ultra-short working distance Hangzhou Zhongwei Optics Co., Ltd. website Checked 2 Oct 2026
A 10mm M12 lens series for machine vision with five aperture options, 1/1.8" sensor format, 6MP resolution, -0.34% distortion, 100–∞ working distance, and M12x0.5 full thread.
A 12 mm M12-mount machine-vision lens with a 1/1.8" maximum image size, 6MP resolution, -0.2% distortion, and five aperture options including F5.6, F7, F8 and F11.
Source & evidence
Supplier website H12FT 12mm FL 1/1.8" Target F5.6 F7 F8 F11 Aperture M12 Mount Lens Product Display PRODUCT FEATURES Product Specifications Product Display M12 series lenses are optimized for machine vision applications. Widely used in measurement, positioning, defect detection and code reading. PRODUCT FEATURES ▶ 5 aperture options F4,F5.6,F7,F8,F11 ▶ Maximum image size 1/1.8" (Φ9 mm) ▶ 6MP high resolution, high image performance ▶ -0.2% Low distortion Hangzhou Zhongwei Optics Co., Ltd. website Checked 2 Oct 2026
16mm autofocus liquid lens for 2/3-inch sensors with 0.5% ultra-low distortion, 84% relative illumination, 6MP resolution, and continuous focus from 100mm to 1m.
Source & evidence
Supplier website M1643AFC-B-ZWA Autofocus liquid lens 16mm 2/3” F4.3 16mm liquid lens autofocus with ultra-low 0.5% distortion and 84% relative illumination . Small size and light weight for space limited device.Continuous focus from 100mm to 1m, 2/3" sensor support, 6MP resolution. Hangzhou Zhongwei Optics Co., Ltd. website Checked 2 Oct 2026
A 16mm M12-mount lens optimized for machine vision, with five aperture options, a maximum 1/1.8-inch image format, 6MP resolution, and -0.17% distortion.
Source & evidence
Supplier website H16HT 16mm EFL 1/1.8 Inch Image Format F4 F5.6 F7 F8 F11 Iris M12 Mount Lens Product Display PRODUCT FEATURES Product Specifications Product Display M12 series lenses are optimized for machine vision applications. Widely used in measurement, positioning, defect detection and code reading. PRODUCT FEATURES ▶ 5 aperture options F4 F5.6,F7,F8,F11 ▶ Maximum image size 1/1.8" (Φ9 mm) ▶ 6MP high resolution, high picture clarity and consistency ▶ -0.17% Low distortion Hangzhou Zhongwei Optics Co., Ltd. website Checked 2 Oct 2026
12mm C-mount autofocus liquid lens for 2/3-inch sensors with F3.8 aperture, 6MP resolution, UART TTL control, and continuous focus from 100mm to 4m.
Source & evidence
Supplier website M1238AFC-C Autofocus liquid lens 12mm 2/3" F3.8 12mm C Mount liquid lens autofocus with F3.8 aperture and 2/3" sensor support. Continuous focus from 100mm to 4m with no moving parts – faster, quieter, and more reliable than traditional motors. Built-in driver board for easy integration. 6MP resolution, UART TTL control. Hangzhou Zhongwei Optics Co., Ltd. website Checked 2 Oct 2026
A 25mm focal-length lens with a 2/3" maximum image format, five aperture options, and 6MP resolution for machine vision applications.
Source & evidence
Supplier website M25FT 25mm FL 2/3" Image Format F4 F5.6 F7 F8 F11 Iris S Mount Lens-Machine vision Lens with M12 mount-Zhongwei Optics English 中文 HOME >> Product >> Machine vision Lens with M12 mount M25FT 25mm FL 2/3" Image Format F4 F5.6 F7 F8 F11 Iris S Mount Lens Product Display PRODUCT FEATURES Product Specifications Product Display M12 series lenses are optimized for machine vision applications. Widely used in measurement, positioning, defect detection and code reading. PRODUCT FEATURES ▶ 5 aperture options F4. F5.6,F7,F8,F11 ▶ Maximum image size 2/3" ▶ 6MP high resolution, high picture clarity and consistency Hangzhou Zhongwei Optics Co., Ltd. website Checked 2 Oct 2026
Machine vision lens with M12 mount, 2/3" image format and 6MP resolution.
Source & evidence
Supplier website M22HT 22mm Focal Length 2/3" Image Format F5.6 F7 F8 F11 Iris S Mount Lens-Machine vision Lens with M12 mount-Zhongwei Optics English 中文 HOME >> Product >> Machine vision Lens with M12 mount M22HT 22mm Focal Length 2/3" Image Format F5.6 F7 F8 F11 Iris S Mount Lens Product Display PRODUCT FEATURES Product Specifications Product Display M12 series lenses are optimized for machine vision applications. Widely used in measurement, positioning, defect detection and code reading. PRODUCT FEATURES ▶ 4 aperture options F5.6,F7,F8,F11 ▶ Maximum image size 2/3" ▶ 6MP high resolution, high picture clarity and consistency Hangzhou Zhongwei Optics Co., Ltd. website Checked 2 Oct 2026
