Laser photoplot film; film size 28" x 32" (710mm x 810mm), image size 27.4" x 31.89" (690mm × 790mm).
Source & evidence
Supplier website 28" x 32" Laser Photoplot film Laser Photoplot Film Film Size: 28" x 32" - 710mm x 810mm Image Size: 27.4" x 31.89" - 690mm × 790mm JD Photo Data Ltd website Checked 3 Oct 2026
Laser photoplot film; film size 12" x 18" (305mm x 457mm), image size 11.6" x 17.6" (295mm x 447mm).
Source & evidence
Supplier website 12" x 18" Laser Photoplot Film Laser Photoplot Film Film Size..... 12" x 18" - 305mm x 457mm Image Size..11.6" x17.6" - 295mm x 447mm JD Photo Data Ltd website Checked 3 Oct 2026
Laser photoplot film; film size 20" x 26" (508mm x 660mm), image size 19.6" x 25.6" (498mm x 647mm).
Source & evidence
Supplier website 20" x 26" Laser Photoplot Film Laser Photoplot Film Film Size..... 20" x 26" - 508mm x 660mm Image Size..19.6" x25.6" - 498mm x 647mm JD Photo Data Ltd website Checked 3 Oct 2026
Laser photoplot film; film size 9" x 12" (228mm x 305mm), image size 8.6" x 11.6" (218mm x 295mm).
Source & evidence
Supplier website 9" x 12" Laser Photoplot Film Laser Photoplot Film Film Size: 9" x 12" - 228mm x 305mm Image size: 8.6" x 11.6" - 218mm x 295mm JD Photo Data Ltd website Checked 3 Oct 2026
Converts existing artworks, photomasks, films, or physical PCBs into usable CAD data.
Source & evidence
Supplier website Our PCB scanning services provide accurate conversion of existing artworks, photomasks, films, or physical PCBs back into usable CAD data. JD Photo Data Ltd website Checked 3 Oct 2026
Idealine CPF is a U.V.-sensitive contact film, suitable for making working copies for printed circuits as well as for cartographic and reprographic applications.
Source & evidence
Supplier website CPF Film Idealine CPF is a U.V.-sensitive contact film, suitable for making working copies for printed circuits as well as for cartographic and reprograp JD Photo Data Ltd website Checked 3 Oct 2026
A standalone auxiliary module for ScanFAB that allows full vectorisation and creation; it does not include a scanner or data import.
Source & evidence
Supplier website ScanFAB Reverse Engineering - AUX ScanFAB AUX is a standalone auxillary module for ScanFAB. It allows full vectorisation and creation. It does not include a scanner nor data import JD Photo Data Ltd website Checked 3 Oct 2026
Converts films, artworks, PCBs and drawings into CAD and GERBER data for production, with quality control and secure file storage.
Source & evidence
Supplier website PCB Scanning - Reverse Engineering Professional reverse engineering and PCB scanning services. We convert films, artworks, PCBs, and drawings back into accurate CAD and GERBER data for production, with full quality control and secure file storage. JD Photo Data Ltd website Checked 3 Oct 2026
A stand-alone scanner-based re-engineering system for creating CAD data from existing PCBs and other listed source materials.
Source & evidence
Supplier website ScanFAB Reverse Engineering ScanFAB is a fully integrated, stand-alone, scanner- based re-engineering system that permits the creation of CAD data (DXF/Gerber/Drill/CNC) from existing multilayer PCBs, parts, phototools, stencils, drawings, microfiche, PDF files, X-Ray images, etc. JD Photo Data Ltd website Checked 3 Oct 2026
Idealine RPF is a red-sensitive line film, part of the Idealine range of films, manufactured by Agfa.
Source & evidence
Supplier website RPF Film Idealine RPF is a red-sensitive line film, part of the Idealine range of films, manufactured by Agfa. JD Photo Data Ltd website Checked 3 Oct 2026
Converts existing artworks, photomasks, films and physical PCBs into CAD data, supporting design modification, manufacturing or inspection.
Source & evidence
Supplier website Our PCB scanning services provide accurate conversion of existing artworks, photomasks, films, or physical PCBs back into usable CAD data. Using advanced flatbed scanning and ScanFAB software, we can digitise legacy designs, reverse engineer existing patterns, or recreate missing documentation with precision. We support a wide range of input materials, including photographic films, printed circuit boards, and chrome photomasks. The scanned data is processed into industry-standard CAD formats, enabling further design modification, manufacturing, or inspection as required. JD Photo Data Ltd website Checked 3 Oct 2026
Drafting & Layout Services
Transfers customers’ notes, sketches, drawings and mark-ups into a clean CAD drawing; the service does not include the design itself.
Source & evidence
Supplier website This does not include the actual design because it is only YOU that knows how the design is going to work - but does include a layout in CAD , transferring your notes, scribbles, drawings and mark-ups into a full clean CAD drawing using suitable formats. JD Photo Data Ltd website Checked 3 Oct 2026
Dimensional measurement
Measures features and dimensions manually or automatically using small- and large-format OGP co-ordinate measuring machines.
Source & evidence
Supplier website We use OGP co-ordinate measuring machines for distance dimensional measuring, utilising both a small and large format machine. These are fully calibrated and serviced on a regular basis, and we can manually or automatically measure a whole range of features and dimensions for you. JD Photo Data Ltd website Checked 3 Oct 2026
Fine individual feature measurement
Uses a Nikon MM40 measuring microscope with camera and video capture to measure features at up to 960 x magnification.
Source & evidence
Supplier website For fine individual feature measurement , we have a Nikon MM40 measuring microscope, with camera and video capture that allows us to measure down to 960 x magnification JD Photo Data Ltd website Checked 3 Oct 2026
2D certified measurement services
Level 2 bespoke measurement service for up to 20 individual measurements, with a certificate returned.
Source & evidence
Supplier website 2D certified measurement services Level 2 bespoke measurement service Upto 20 individual measurements Certificate returned JD Photo Data Ltd website Checked 3 Oct 2026
Custom photomask, optical test target, and calibration plate production
Rapid production of custom photomasks, optical test targets, and calibration plates.
Source & evidence
Supplier website JD Photo Data is the global leader in rapid production of custom photomasks, optical test targets, and calibration plates JD Photo Data Ltd website Checked 3 Oct 2026
Photoplotted Film Calibration Level 2
Monthly calibration with a photoplot file provided and a certificate returned.
Source & evidence
Supplier website Photoplotted Film Calibration Level 2 Monthly Calibration Photoplot file provided Certificate returned JD Photo Data Ltd website Checked 3 Oct 2026
Technical support
Responsive technical assistance for orders and enquiries.
Source & evidence
Supplier website we provide exceptionally fast, responsive support and technical assistance for all orders and enquiries. JD Photo Data Ltd website Checked 3 Oct 2026
Optical Density measurement
Optical Density measurement for thin and thick films.
Source & evidence
Supplier website On top of that, we can offer Optical Density measurment for thin and thick films alike. JD Photo Data Ltd website Checked 3 Oct 2026
PCB reverse engineering
Reverse engineering of PCBs back to CAD data.
Source & evidence
Supplier website reverse engineering of PCB's back to CAD data JD Photo Data Ltd website Checked 3 Oct 2026
Agfa film and chemistry supply
Supply of Agfa film and chemistry.
Source & evidence
Supplier website and supplying Agfa film and chemistry. JD Photo Data Ltd website Checked 3 Oct 2026
PCB supply
Supply of PCBs.
Source & evidence
Supplier website Our PCB services include the supply of PCB's JD Photo Data Ltd website Checked 3 Oct 2026
